Minn Kota PowerDrive V2 54 Pontoon Parts. Cannon Manual Downrigger Parts. Minn Kota Trolling Motors Parts Schematics - 2016. This section of your boat manual contains important informa. Providing instruction for obtaining warranty service. Going over the pre-delivery service.
Does losing AC power or unplugging the Precision charger from an AC outlet affect battery type selection? No, once a battery type is selected it will be stored until a new battery type is selected by the user. Does losing AC power or unplugging the Precision charger from an AC outlet affect Deep Equalization mode? Yes, the Deep Cycle mode is cancelled and the charger will restart the charging cycle in normal Flooded Lead Acid battery mode. Does Minn Kota's original Universal Sonar transducer support temperature and speed functions? No, Universal Sonar does not support these functions.
The new Universal Sonar 2 feature offers a transducer that has an array of built-in temperature sensors that will display wate. Does the Minn Kota Talon shallow water anchor have a fuse? What size is it? Where can I purchase the fuse? Yes, Talon has an in-line 30A blade style fuse. These can be purchased at any automotive parts store. Does Universal Sonar 2 support temperature sensing?
The US2 transducer has an array of built-in temperature sensors that will display water temperature on most major fishfinder brands that have this feature. Please refer to our. Does your company offer a program for Pro Staff or licensed guides?
Minn Kota Powerdrive V2 Pontoon
Please visit our Sponsorship Page for complete details about the programs we have to offer. Electric motor power ratings are in pounds of thrust. How do I determine the thrust requirements for my boat? Thrust requirements are determined by the size and weight of your boat. We suggest selecting a trolling motor with at least 2 lbs of thrust for every 100 lbs of boat weight when fu. How can I get technical information about my Minn Kota product? If you already own a Minn Kota trolling motor or Minn Kota product, please refer to the original product manual for any respective technical information.
If you are inquiring abo. How can I test the performance of the Universal Sonar 2 transducer to see if it is functioning properly? Test the depth finder with the OEM (Original Equipment Manufacturer) supplied transducer. Compare the performance with the Universal Sonar 2 transducer. If depth finder does not fu.
How do I clean my 10' or 12' Talon Shallow Water Anchor? We recommend, as part of your normal routine, to rinse the Talon after each use to minimize any build up on the anchor. 30 second deep water rinse.
(Recommended) A. Before doc How do I connect my deep cycle batteries in series?
Please for a detailed drawing on how to wire your deep cycle batteries for either 24 or 36 volts. How do I determine what battery type is selected on my Minn Kota PC Charger? Press and release the “BATTERY SELECTION” button. The yellow LED located next to the corresponding battery type selected will illuminate for 2 seconds. How do I determine where and how to mount my Minn Kota Talon shallow water anchor?
This will vary from one boat to the next. It is important to check for proper steering and trimming clearances when laying out your installation. See the Talon installation guide. How do I install the i-Pilot trolling motor system on my Minn Kota Terrova, PowerDrive V2, Riptide ST or Riptide SP? See how to install the i-Pilot trolling motor system on your PowerDrive V2 or Riptide SP. See how to install the i-Pilot trolling motor system on your Terrova or R How do I know when I should use a mounting bracket for the Minn Kota Talon shallow water anchor?
Some boats have irregular shaped transoms and the standard Talon quick release mounting bracket cannot be mounted directly to the transom. In other cases there are other accessor How do I learn the Micro Remote to my i-Pilot or i-Pilot Link? LEARNING THE MICRO REMOTE TO YOUR CONTROLLER.
1. Power up the trolling motor. Push and hold the learn button down.
A steady audio tone will be heard while holding this button. W How do I mount a Minn Kota Talon shallow water anchor when I have Trim Tabs? Talon requires a minimum of 6' of clearance from the mounting surface. If further clearance is required, or it is necessary to mount over top of trim tabs, Minn Kota offers a 6' How do I set Equalization mode on my Minn Kota Precision charger?
Minn Kota Precision Chargers feature Automatic Equalization Technology that cleans and conditions batteries with each charge cycle (flooded Lead-Acid only) Precision Chargers a How do you change audible modes for CoPilot? UNIT IS FACTORY PRE-SET TO AUDIO MODE 2 There are three receiver audio modes available. To switch from one audio mode to another, press and hold both the INCREASE and DECREASE spe How do you program and learn a CoPilot remote?. The CoPilot kit already has the receiver 'learned' to the ID number of the remote it is packaged with.
To 'learn' the ID number of additional remotes, follow these steps: How does horsepower compare to thrust? How do I convert thrust into horsepower? Many people think that the more pounds of thrust they are getting, the faster the boat will go. This is not exactly true. With trolling motors and outboard motors, boat speed (an.
How does thrust compare to speed? 'My buddy has a 36-lb thrust motor, we have the same size boat yet his motor moves his boat just as fast as my 42-lb thrust unit. Why is this?' . Again, thrust is simply a static meas How far is the remote range? The maximum safe operating range of the Co-Pilot, Talon, i-Pilot and i-Pilot Link remotes is 30 ft.
How important is battery selection for electric motor usage? The battery is a critical element of your electric motor system. A high-quality deep cycle marine battery should always be used. Unlike automobile batteries, deep cycle marine ba.
How is the maximum deployment of the Minn Kota Talon shallow water anchor measured? From the bottom of the Talon shallow water anchor to the tip of the spike when fully deployed. How long are the cords on the EM (Engine Mount) units from the factory? The length of the two conductor leads coming from the control module output (the wires going to the motor unit), are only about one foot long. The length of wire that comes from th. How long are the steering cables on an Edge, Maxxum, or Fortrex model?
The steering cables are 5 ft. Long and cannot be extended. How long of an iTrack can I record?
Each individual iTrack can be up to two miles in length. How long will batteries in my CoPilot remote and wireless foot pedal last? Typically the batteries will last one year or at least two regular fishing seasons. How often should I perform Deep Equalization? Deep Equalization is recommended every 30th charge cycle. How warm do Minn Kota battery chargers get? The Minn Kota battery chargers can reach 150 degrees.
They may get warm in an enclosed area. The maximum recommended room temperature is 122º F. If the charger seems to get 'hot,'. I am upgrading from a trolling motor with Universal Sonar to a trolling motor with Universal Sonar 2 - is there anything special I should do?
Some Universal Sonar users installed the optional fused ground wire between the grounds of their trolling motor batteries and starting battery. If this is your situation, this wir If I adjust the Minn Kota Talon shallow water anchor extrusion lower to the water, do I gain more depth? But the user must be aware that Minn Kota recommends a minimum of 4' up from the bottom of the hull line to minimize spray. Dragging the Talon through the water while underway. If I currently have a CoPilot on my trolling motor, can I install the i-Pilot system? Yes, however i-Pilot will override CoPilot so the CoPilot system will no longer be functional. I-Pilot includes all the features of CoPilot.
If I currently have a trolling motor with the AutoPilot feature, can I install the i-Pilot system? Yes, however the AutoPilot will need to be uninstalled from your trolling motor before you install i-Pilot. I-Pilot includes all of the functionality of AutoPilot. If I hit Spot-Lock on the foot pedal, which Spot-Lock position on the remote is used? When Spot-Lock is activated from the foot pedal it will always utilize position “A” on the remote. The Alternator charger is designed to only begin charging trolling motor batteries after the starting battery has been fully charged.
Motor Thrust / Model Max Amp Draw Circuit Breaker Wire Extension Length. 5 feet 10 feet 15 feet 20 feet 25 feet 30 lb. 30 50 Amp @ 12 VDC 10 AWG 10 AWG 8 AWG 6 AWG 4 AWG 40 lb., 45 lb. 42 10 AWG 8 AWG 6 AWG 4 AWG 4 AWG 50 lb., 55 lb. 50 60 Amp @ 12 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG 70 lb. 42 50 Amp @ 24 VDC 10 AWG 10 AWG 8 AWG 8 AWG 6 AWG 80 lb.
56 60 Amp @ 24 VDC 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG 101 lb. 46 50 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG Engine Mount 101 50 60 Amp @ 36 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG 112 lb. 52 60 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG Engine Mount 160 116 (2) x 60 Amp @ 24 VDC 2 AWG 2 AWG 2 AWG 2 AWG 2 AWG E-Drive 40 50 Amp @ 48 VDC 10 AWG 10 AWG 10 AWG 10 AWG 10 AWG This conductor and circuit breaker sizing table is only valid for the following assumptions:.
No more than 3 conductors are bundled together inside of a sheath or conduit outside of engine spaces. Each conductor has 105° C temp rated insulation. No more than 5% voltage drop allowed at full motor power based on published product power requirements.Wire Extension Length refers to the distance from the batteries to the trolling motor leads. I-Pilot & i-Pilot Link Materials:. i-Pilot Link Software Updates: Your i-Pilot Link remote and controller software are updated through the Humminbird Fishfinder. For i-Pilot Link software updates. You will be redirected to the Humminbird website. Please refer to your i-Pilot Link User’s Manual for more detailed instructions.
Required Equipment: Personal computer with Internet access, a formatted SD memory card, a USB Memory Card Reader (AS CR), and an i-Pilot Link compatible Humminbird Fishfinder. November 25th, 2014 Summary: High-Speed Bypass, Prop Auto-On and Micro Remote compatibility Please Note: Make sure you have the latest software version in your Humminbird unit. I-PILOT & i-PILOT LINK REFERENCE MATERIALS:. i-Pilot (model year 2017 or after). Heading Sensor (model year 2017 or after).
i-Pilot Link (model year 2017 or after). i-Pilot Link (model year 2016 or earlier). i-Pilot (model year 2016 or earlier). i-PILOT & i-PILOT LINK SOFTWARE UPDATES:. i-PILOT LINK (model year 2016 or earlier) Your i-Pilot Link remote and controller software can be updated only through the Humminbird Fishfinder. Follow the below instructions to update your software:. Go to.
Log into My Humminbird. Solution manual for robert gibbons. Download the latest i-Pilot Link software to a formatted SD memory card. Insert SD card with new software into memory card slot in your Humminbird Unit You will be redirected to the Humminbird website.
Please refer to your i-Pilot Link User’s Manual for more detailed instructions. Required Equipment: Personal computer with Internet access, a formatted SD memory card, a USB Memory Card Reader (AS CR), and an i-Pilot Link compatible Humminbird Fishfinder. i-PILOT LINK (model year 2017 or after) Your i-Pilot Link remote and controller software can be updated through the Humminbird Fishfinder or your i-Pilot Link mobile app. TO UPDATE VIA YOUR FISHFINDER:.
Go to. Log into My Humminbird. Download the latest i-Pilot Link software to a formatted SD memory card.
Insert SD card with new software into memory card slot in your Humminbird Unit You will be redirected to the Humminbird website. Please refer to your i-Pilot Link User’s Manual for more detailed instructions. Required Equipment: Personal computer with Internet access, a formatted SD memory card, a USB Memory Card Reader (AS CR), and an i-Pilot Link compatible Humminbird Fishfinder. TO UPDATE VIA THE MOBILE APP:. Download the i-Pilot Link app from the iOS or Android app store. Open the i-Pilot Link application from the device.
Check to see if the application update indicator icon in the upper right hand corner is present. If no icon is present, the device is up-to-date. If the Application Update Indicator icon is present, select it. An Update Software screen will appear. Begin by pressing the “Press to Begin Update” on the screen.
Follow the on-screen prompts to successfully complete the update. I-PILOT LINK APP. UNIVERSAL SONAR 2 COMPATIBILITY A Universal Sonar 2 adapter plug will allow you to quickly and conveniently connect and disconnect your motor from your fishfinder. Shielded cable connections virtually eliminate the possibility of sonar interference and are waterproof for extra dependability. Universal Sonar 2’s state-of-the-art, integrated and protected transducer is built into the lower unit of the motor and all wiring runs inside the indestructible composite shaft - out of sight and out of harm’s way. No exposed wires or connections. You get optimal sonar performance to help you find fish.
